Chimie chimique de la batterie : LFP
Tension nominale de la batterie : 25,6 V
Nominal battery capacity: 230Ah / 304Ah / 314Ah
Nominal battery energy capacity: 5.888kwh / 7.782kwh / 8.038kwh
| 24V,230Ah-HV | 24V, 304 / 314Ah-HV | |
| Chimie des batteries | Lithium lron Phosphate | |
| Nominal battery voltage | 25,6 V | |
| Nominal battery capacity | 230 Ah | 304 / 314Ah |
| Nominal battery energy capacity | 5,888 kWh | 7.782 / 8.0384kwh |
| Cycle de vie | 3500 cycles@ 0.5C/0.5C @25±2°C | |
| Battery monitoring | intégré | |
| MasterBus communication | Oui | |
| Communication / Ports | CAN 2.0 * 2 channel + RS485* 1 channel | |
| Terminaux | Quick plug | |
| Mounting position | long side | |
| Product weight (aluminium/stainless steel) | 44kg / 52kg | 54.5kg / 64.5kg |
| Dimension（L*W*H） | 620×232×294.2mm | 750×232×289.2mm |
| Protection degree | IP67 | |
| Series/Parallel mix connection | Max. 6P50S | |
| Charge Mode | Support AC slow charging & DC fast charging | |
| protections | over/under voltage, over/under current, over/under temperature | |
| Safety relay | intégré | |
| Pre-charge Function | intégré | |
