| Item | Technical parameters(compatible with 215kWh/261kWh/ 372 kWh/417KWh) |
||||
| Basic system parameters |
Cell type | 3.2V/280Ah, LFP |
3.2V/314Ah, LFP |
3.2V/280Ah, LFP |
3.2V/314Ah, LFP |
| System rated capacity |
215KWh | 261KWh | 372KWh | 417KWh | |
| Battery grouping method |
5*1P48S | 5*1P52S | 8*1P52S | 8*1P52S | |
| Charge and discharge rate |
≤0.5P | ||||
| System efficiency | ≥86% | ||||
| Operating temperature range |
Discharge:-20~55℃;Charge:0~55℃ | ||||
| UPS | Off-grid option | ||||
| Fire fighting method | Perfluorohexanone/aerosol optional | ||||
| Communication | RS485、Modbus-TCP、LAN | ||||
| Cooling method | Liquid cooling | ||||
| IPlevel | IP54 | ||||
| Corrosion resistance level |
C4 | ||||
| Weight | 2.4t | 2.5t | 4.3t | 4.5t | |
| Size(W*DH mm) | 1000*1350*2350 | 1400*1400*2450 | |||
| Max.operating ltitude |
5000m | ||||
| Temperature range | 0~95%(no condensation) | ||||
