| S/N |
Parameters |
Product Model |
Remarks |
| LF105-1P4S |
LF105-1P8S |
LF105-2P4S |
| 1 |
Cell Model |
LF105 |
LF105 |
LF105 |
|
| 2 |
Nominal Capacity (AH) |
105 |
105 |
210 |
|
| 3 |
Nominal Voltage (V) |
12.8 |
25.6 |
12.8 |
3.2 V x cell series |
| 4 |
Nominal Energy (kwh) |
1.344 |
2.688 |
2.688 |
3.2V*Nominal capacity |
| 5 |
L (mm) |
191.7 |
338.5 |
338.5 |
Refer to Drawing below
|
| 6 |
W (mm) |
136.6 |
136.6 |
136.6 |
| 7 |
H(mm) |
212.4 |
212.4 |
212.4 |
| 8 |
Weight (kg) |
9.5 |
18.1 |
18.1 |
|
| 9 |
Operation Voltage(V) |
10~14.6 |
20~29.2 |
10~14.6 |
Single cell 2.5~ 3.65V |
| 10 |
Operation Temperature |
Charge: -20~ 55°C |
With heating pad |
| Discharge: -20~ 55°C |
| 11 |
Cycle Life |
3500 cycles @ 0.5C/0.5C @ 25±2°C |
|
