| 48V-320 AH | 48V-460AH | 48V-608AH | |
| Battery chemistry | Lithium Iron Phosphate | ||
| Nominal battery voltage | 51.2V | ||
| Nominal battery capacity | 320Ah | 460Ah | 608Ah |
| Nominal battery energy capacity | 16.384kwh | 23.552kwh | 31.129kwh |
| Cycle life | >3500 cycles @0.5C/0.5C ,25±2℃ | ||
| Recommended max. continuous charge current |
160A | 230A | 304A |
| Recommended max.continuous discharge current |
256A | 368A | 486A |
| Peak discharge current | 480A(10s) | 690A(10s) | 912A(10s) |
| Battery monitoring | integrated | ||
| MasterBus communication | yes | ||
| Communication | CAN | ||
| Terminals | Quick plug | ||
| Product weight(kg/lbs) | 122/268.4 | 160/352.74 | 200/440.92 |
| Dimension(L*W*H mm) | 806*556*186 | 800*550*230 | 1000*550*230 |
| Dimension(L*W*H Inches) | 31.73*21.89*7.32 | 31.5*21.65*9.06 | 39.37*21.65*9.06 |
| Protection degree | IP67 | ||
| Protections | over/under voltage,over/under current,over/under temperature | ||
