| 48V-230Ah | |
| Battery chemistry | Lithium Iron Phosphate |
| Nominal battery voltage | 51.2V |
| Nominal battery capacity | 230Ah |
| Nominal battery energy capacity | 11.77kwh |
| Cycle life | 3500cycles@0.5C/0.5C @25±2℃ |
| Recommended max. continuous charge current |
115A |
|
Recommended max.continuous discharge current |
230A |
| Peak discharge current | 350A @10S |
| Battery monitoring | support |
| Communication | CAN/RS485 |
| Terminals | Terminal Blocks |
| Product weight (kg /Ibs) | 85/187.39 |
| Dimension(L*W*H mm) | 580*400*240 |
| Dimension(L*W*H Inches) | 22.83*15.75*9.45 |
| Protection degree | IP65 |
| Protections | Overvoltage,undervoltage,overcurrent,overtemperature,low temperature,etc. |
