| 24V-160AH | 24V-230AH | 24V-304AH | |
| Battery chemistry | Lithium Iron Phosphate | ||
| Nominal battery voltage | 25.6V | ||
| Nominal battery capacity | 160Ah | 230Ah | 304Ah |
| Nominal battery energy capacity | 4.096kwh | 5.888kwh | 7.782kwh |
| Cycle life | >3500 cycles @0.5C/0.5C ,25±2℃ | ||
| Recommended max. continuous charge current |
80A | 115A | 152A |
| Recommended max.continuous discharge current |
128A | 184A | 243A |
| Peak discharge current | 240A(10s) | 345A(10s) | 456A(10s) |
| Battery monitoring | integrated | ||
| MasterBus communication | yes | ||
| Communication | CAN | ||
| Terminals | Yinfeel connector | ||
| Product weight(kg/lbs) | 39/85.8 | 45/99.21 | 58/127.87 |
| Dimension(L*W*H mm) | 606*246*206 | 650*250*230 | 750*240*230 |
| Dimension(L*W*H Inches) | 23.86*9.69*8.11 | 25.59*9.84*9.06 | 29.53*9.45*9.06 |
| Protection degree | IP67 | ||
| Protections | over/under voltage,over/under current,over/under temperature | ||
