التركيب الكيميائي للبطارية: فوسفات الحديد الليثيوم
الجهد الاسمي للبطارية: 25.6 فولت
Nominal battery capacity: 205Ah
Nominal battery energy capacity: 5.25kwh
24V System
Delivers stable and reliable power for pallet trucks and stackers, supporting consistent performance throughout daily material-handling operations.
Wide Temperature Range
Designed to operate reliably across a wide temperature range of -20°C to 55°C, making it suitable for demanding indoor and outdoor working environments.
Compact Structure
Features a compact and space-saving design that optimizes available installation space while allowing easy integration into different types of material-handling equipment.
Safe & Reliable
Equipped with an intelligent BMS (Battery Management System) for real-time monitoring and protection of key battery parameters, helping ensure safe, stable, and reliable operation.
| 25.6 فولت - 205 أمبير/ساعة | |
| كيمياء البطاريات | Lithium lron Phosphate |
| Nominal battery voltage | 25.6 فولت |
| Nominal battery capacity | 205Ah |
| Nominal battery energy capacity | 5.25kwh |
| دورة الحياة | 3000 cycles @ 0.5C/0.5C @ 25±2°C |
| Battery monitoring | Support |
| تواصل | يستطيع |
| المحطات | Rema connector |
| Product weight (kg / lbs) | 62 / 136.69 |
| Dimension（L*W*H mm） | 550*195*500 |
| Dimension（L*W*H Inches） | 21.7*7.7*19.7 |
| Protection degree | IP54 |
| الحماية | Overvoltage, undervoltage, overcurrent, overtemperature, low temperature, short circuit, etc. |
| Safety relay | يدعم |
| Safety relay controls | يدعم |
